Equipped with a multilingual keyboard overlay
Equipped with AMD Ryzen™ 3 4300U
Fast response and high memory capacity
Slim structural design
HD Video Conferencing
Slim design
Interface
Specifications
Processor
-
CPU
AMD Ryzen™ 3 4300U
4 Cores/4 Threads
Technology for CPU Cores: TSMC 7nm FinFET
4 MB L3 Cache
Base Clock Frequency: 2.7 GHz
Maximum Turbo Frequency: Up to 3.7 GHz
TDP: 15-28 W -
GPU
AMD Radeon™ Graphics
Graphics Core Count: 5
Memory & Storage
-
Memory
16GB DDR4 2666MHz
DDR4 SO-DIMM Slots ×2, up to 64GB
Supports up to DDR4 3200MHz -
Storage
512GB M.2 2280 SATA SSD
2*M.2 2280 Slots
1 slot supports M.2 NVMe PCIe 3.0 SSD or M.2 SATA SSD
1 slot supports M.2 NVMe PCIe 3.0 SSD
Maximum capacity per drive: 2TB
Total maximum capacity: 4TB
Wireless Connectivity
- WiFi WiFi 5
- Bluetooth BT 5.0
Screen
- Size 17.3" 16:9
- Resolution 1920*1080 60Hz
Camera & Battery
- Camera 1MP(1280*720)
- Battery 11.4 V/5500 mAh 62.7Wh
Ports & Buttons
-
Ports & Buttons
USB 3.2 *3
3.5 mm headphone jack *1
DC IN *1
HDMI 1.4 *1
Type-C (Data) *1
TF *1
Keyhole *1
Base Configuration
- Power DC 19V/3.42A
- System Windows 11 PRO
- Dimension 396.4*249.93*20.19mm
Customer Reviews
Frequently Asked Questions
About keyboard layout
All laptops have a QWERTY keyboard layout and are equipped with a multilingual keyboard membrane (German, French, Italian, and Spanish).
Is an operating system already installed on the AX17 computer?
Except for the barebone configurator, all other configurations come with Windows 11 preinstalled.
How do you fix problems with charging, the touchpad, numeric keypad, and function keys on an AX17 laptop?
What should I do if the screen of my AX17 laptop has no backlight?
Is there an instruction manual for the AX17?
What is the screen refresh rate of the AX17?
The screen refresh rate of the AX17 is 60 HZ
System download link
All driver download links
Graphics card driver links
