Pre-orders will start shipping on May 7. Pre-order now to secure yours at a special early price!
Save
$50
Get the F5A H255 for only $599
Copy Code
F5A H 255 MINI PC
Powerful Performance, Smooth in Every Way
Efficient Memory, Upgraded Performance
Efficient Cooling System
Hardware security protection
OCuLink
4-screen Display, Efficient Work
2-years Warranty
What's in The Box?
Specification
Processor
-
CPU
AMD Ryzen™ 7 H 255
8 Cores/16 Threads
Processor Architecture: TSMC 4nm FinFET
16MB L3 Cache
Base Clock Frequency: 3.8GHz
Maximum Turbo Frequency: 4.9GHz
TDP: 65W -
GPU
AMD Radeon™ 780M
Graphics Clock Speed: 2700 MHz
Number of Graphics Cores: 12
Memory & Storage
-
Memory
24GB LPDDR5 6400MT/s
Not Expandable or Upgradeable -
Storage
1TB M.2 2280 NVMe PCIe 4.0 x4 SSD
3x M.2 2280 Slots, 3 Drive Slots Support M.2 NVMe PCIe 4.0 x4 SSDs, Up to 6 TB
Does Not Support SATA SSDs
Wireless Connectivity
- WiFi WiFi 6E
- Bluetooth Bluetooth 5.2
Output
-
Video
HDMI 2.1 x1 (8K@60Hz）
USB4 Type-C x2
DP2.1 x1 (8K@60Hz) - Audio 3.5 mm Audio Jack ×1
Ports & Buttons
-
Ports & Buttons
2 x 10/100/1000 Mbps/2.5 Gbps auto-negotiating RJ45 Gigabit Ethernet ports
2 x USB 3.2 Gen 2 Type-A ports (10 Gbps) – front panel
1 x USB 3.2 Gen 2 Type-A port (10 Gbps) – rear panel
1 x USB 2.0 Type-A port – rear panel
2 x USB4 Type-C (Supports DP 1.4, 4K@60Hz, up to 40Gbps data transfer, PD output)
1 x DC IN
1 x HDMI 2.1
1 x DP 2.1
1 x 3.5mm Audio Jack
1 x Power Button
1 x OCuLink Port (Supports external discrete graphics)
Base Configuration
- Power DC 19 V-6,3 A, 5.5 x 2.5 mm DC connector
- System Windows 11 PRO
- Dimensions 130 × 132 × 62mm
Cooling System
- Dual Fans (CPU Fan + System Fan) + Uniform Heat Dissipation Plate (VC), Maximum Power of 65 W
