ACEMAGIC F2A Intel® Core™ Ultra X7 358H/AMD Ryzen AI9 HX 470 Mini PC
- $0.00
- $0.00
- Unit price
- per
Pre-orders will start shipping on July 27th. Pre-order now to secure yours at a special early price!
Fast, Free shipping
US Delivery in 3–5 Business Days
30-Day Money-Back Guarantee
2 Years Warranty
F2A Mini PC
USB4 Connectivity with External GPU Expansion Support
WiFi 7 + Dual 2.5Gbps High-Speed Networking, Stable Low-Latency Connectivity
All-in-One Type-C Port
2-Year Warranty
Specification
Intel® Core™ Ultra X7 358H
AMD Ryzen AI9 HX 470
Processor
-
CPU
Intel® Core™ Ultra X7 358H(Panther Lake)，16 cores (4P + 8E + 4 LP-E), 16 threads
Intel 18A process, base frequency 1.9GHz, max turbo up to 4.8GHz
18MB Smart Cache, NPU up to 50 TOPS
total platform AI performance up to 180 TOPS -
GPU
Intel Arc B390 Graphics
Xe3 architecture, 12 Xe-Cores, max frequency up to 2.5GHz, up to 122 TOPS AI compute, DirectX 12 Ultimate, Ray Tracing support, XeSS support, AV1 / H.265 / H.264 encode and decode, up to 8K output, up to 4 displays -
NPU
Intel® AI Boost NPU（NPU 5 Architecture）
Up to 50 TOPS NPU AI performance
Total AI Performance (CPU+GPU+NPU): Up to 180 TOPS
Memory & Storage
- Memory 32GB LPDDR5X 7500MT/s (onboard, non-upgradable)
-
Storage
1× M.2 2280 NVMe PCIe 4.0×4 SSD (1TB pre-installed)
2× M.2 2280 NVMe slots (1× PCIe 4.0×4, 1× PCIe 5.0×4)
Up to 2TB per slot, maximum total 4TB
Wireless Connectivity
- WiFi WiFi 7
- Bluetooth Bluetooth 5.4
- LAN Dual 2.5Gbps LAN
Output
-
Video
1× HDMI 2.1 TMDS (4K@60Hz)
1× DP 2.1 (8K@60Hz)
USB4 Type-C [Supports DP 1.4 display + supports USB4 transfer protocol (40 Gbps) + supports PD 100 W input and 15 W output]
Full-featured Type-C [Supports DP 1.4 display + supports PD 100 W input + supports USB 3.2 Gen 2 transfer protocol (10 Gbps)] - Audio 1× 3.5mm audio jack
Ports & Buttons
-
Ports & Buttons
Front:
1× USB4 Type-C
2× USB 3.2 Gen2 Type-A
1× 3.5mm audio jack
1× Power button
1× reset button
Rear:
1× HDMI 2.1 TMDS
1× DP 2.1
2× 2.5GbE LAN
1× Full-featured USB-C (20Gbps, PD 100W, DP1.4)
2× USB 3.2 Gen1 Type-A
1× DC-in
1× Security keyhole
Base Configuration
- Power DC 19V / 6.32A, 5.5×2.1mm connector, up to 65W TDP design
- System Windows 11 Pro pre-installed, Linux / Ubuntu supported
- Dimensions 128 × 128 × 37 mm (excluding rubber feet)
Features
-
Features
Supports quad-display output with 4K/8K resolution capability (HDMI 2.1 TMDS + DP 2.1 + USB4 + Full-Function USB 3.2 Gen 2 Type-C)
Delivers powerful 180 TOPS AI computing performance (CPU + GPU + NPU collaborative processing) -
TDP
25-65W (PL2 65W, PL1 54W )
Max Design Power: 65W
Stable Sustained Power: 54W
Low Power Mode: 25W
Processor
-
CPU
AMD Ryzen AI9 HX 470
12 cores / 24 threads (4 Zen 5 cores + 8 Zen 5c cores)
Architecture: Zen 5 + Zen 5c hybrid architecture
Base Clock: 2.0 GHz
Max Boost Clock: Up to 5.2 GHz
Cache: 12MB L2 + 24MB L3
Process Technology: TSMC 4nm FinFET -
GPU
Integrated AMD Radeon™ 890M Graphics (RDNA 3.5 Architecture)
16 Compute Units
Up to 3.1 GHz
Support DirectX® 12，DisplayPort™ 2.1 (Support UHBR10, Adaptive-Sync, HDR) -
NPU
Integrated AMD Ryzen AI Engine (XDNA2 architecture)
Up to 55 TOPS NPU AI performance
Total AI Performance (CPU+GPU+NPU): Up to 86 TOPS
Memory & Storage
- Memory 32GB LPDDR5X 7467MT/s (onboard, non-upgradable)
-
Storage
2× M.2 2280 NVMe Slots（2*PCIe4.0x4 Slots）
Supports PCIe 4.0x4 NVMe SSD
SATA M.2 SSD Not Supported
Up to 4TB per Slot (8TB Total)
Wireless Connectivity
- WiFi WiFi 7
- Bluetooth Bluetooth 5.4
- LAN Dual 2.5Gbps LAN
Output
-
Video
1× HDMI 2.1 TMDS (4K@60Hz)
1× DP 2.0 (8K@60Hz)
USB4 Type-C [Supports DP 1.4 display + supports USB4 transfer protocol (40 Gbps) + supports PD 100 W input and 15 W output]
Full-featured Type-C [Supports DP 1.4 display + supports PD 100 W input + supports USB 3.2 Gen 2 transfer protocol (10 Gbps)]
Ports & Buttons
-
Ports & Buttons
Front:
1× USB4 Type-C
2× USB 3.2 Gen2 Type-A
1× 3.5mm audio jack
1× Power button
1× reset button
Rear:
1× HDMI 2.1 TMDS
1× DP 2.0
2× 2.5GbE LAN
1× Full-featured USB-C (20Gbps, PD 100W, DP1.4)
2× USB 3.2 Gen1 Type-A
1× DC-in
1× Security keyhole
Base Configuration
- Power DC input 19V/6.32A, DC connector 5.5 × 2.1 mm
- System Windows 11 Pro pre-installed, Linux /Ubuntu supported
- Dimensions 128 × 128 × 37 mm (excluding rubber feet)
Features
-
Features
Supports quad-display output with 4K/8K resolution capability (HDMI 2.1 TMDS + DP 2.0 + USB4 + Full-Function USB 3.2 Gen 2 Type-C)
Delivers powerful 86 TOPS AI computing performance (CPU + GPU + NPU collaborative processing) - TDP PL2 65W, PL1 54W
